Key Features
2K HD, 30 FPS camera with a 5MP CMOS sensor.
Wide-angle view (102.4°)
Weatherproof IPX4-rated enclosure with IK08-rated vandal resistance.
Improved low-light performance and IR night vision up to 10m.
Improved dynamic range

Works with the UniFi Protect Application
Plug-and-play installation
Designed for scalability
Intuitive user interface
Powerful mobile app
Subscription-free

Specifications

Mechanical
Dimensions
Ø109.2 x 64.5 mm (Ø4.3 x 2.5 )

Weight
390 g (13.76 oz)

Enclosure materials
Aluminum alloy, polycarbonate, hard-coated dome

Mount materials
Polycarbonate, stainless steel

Weatherproofing
IPX4

Resistance
IK08

Optics

Sensor
5MP CMOS sensor

Lens
Fixed focal length

View angle
H: 102.4°, V: 71.4°, D: 134.3°

Night mode
Built-in IR LED illumination and IR cut lter

Video

Video compression
H.264, MJPEG

Resolution
2688 x 1512 (16:9)

Max frame rate
30 FPS

Image settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay

System

Processor
specs Dual-core Arm Cortex -A7 based chip

Networking interface
10/100 MbE RJ45

Max power consumption
5W

Power method
PoE

Supported voltage range
37? 57 VDC

LED
R/G/B/W

Button Factory
reset

Mounting
Wall, ceiling mount

Operating temperature
-20 to 40º C (-4 to 104º F)

Operating humidity
0 to 90% non-condensing

Certifications
FCC, IC, CE

Audio

Microphone
Yes (Can be disabled in software)

Speaker
Yes

Software

UniFi OS application
UniFi Protect

Mobile app
UniFi Protect iOS and Android

Box contents
1 x UVC-G5-DOME
1 x Tightening Tool
1 x Pole Mount Bracket
1 x Wall Mount Kit (Screws Included)
